EEMUE41
EEMUE41
- PCIe to 4 mini PCIe with SIM slot
- Compliant PCI express base SPEC2.0 and backward compatible with SPEC 1.1 & 1.0a..
- Compliant PCI Power management SPEC 1.2
- Support 4 Ports Mini PCIe (PCIe & USB)
- Support Micro SIM.
- Compliant with Universal Serial Bus Specification Revision 2.0, witch is released by USB Implementers Forum, Inc
- Supports the following data rates as follows: Low-speed(1.5Mbps) / Full-speed (12Mbps) / High-speed(480M bps)
- Certified by CE, FCC, RoHS, and Microsoft WQHL approval.
|
Mode Name
|
EEMUE41
|
|
Key Type
|
PCI Express x1 |
|
Chipset ID
|
PCIe: Asmedia ASM1184e USB: Renesas uPD720115 |
|
Number of Ports
|
4 Mini PCIe Support Half / Full Sie SIM Card Holder Support Micro SIM Card |
|
Dimensions
|
167.75. (W）x 99.65（L）mm |
|
Operating Temperature
|
0°C to 70°C |
| Storage Temperature | -20°C to 90°C |
|
OS Compatibility
|
Windows 7/ 8.x / 10 |
