EGS0041

  • M.2 B+M KEY 4-PORT SATA III
  • Connect four SATA drives to a M.2 B+M key Connection, providing up to 1700 MB/s Speed.
  • Plug and play supported, No additional software installation or setting required.
  • Can support port Multiplier that is not in a RAID configuration. Compatible with SATA hard drives & Solid state drives and computer systems with SATA controllers.
  • 2-Lane M.2 PCI-Express 3.0 interface (B & M Key). complies with PCI Express base Specification Revision 3.1a.
  • This card is only design for storage Use only, can not Boot any OS/ system drives.
HARDWARE
Mode Name EGS0041
Bus Type M.2 b+M Key
Card Type M.2 2280
Chipset ID ASMedia ASM1064
Interface SATA III
Port Numbers 4

PERFORMANCE
Type and Rate SATA III (6 Gbps)
Port Multiplier Yes
Number of Ports That Support Port Multiplier 4 (can only use 1 PM at a time)
Number of Drives Supported Through Port Multiplier 1 to 4
LBA support 48-bit
ATAPI Support Yes
Max Drive Capacity Currently tested up to 4TB per drive
Hot Swap Capability Yes

CONNECTOR(S)
Connector Type(s) 1 m.2 B+M Key
External Ports SATA (7 pin, Data)

System Requirements
Windows® 2000, CE 5.0/6.0, Embedded System 2009, POS Ready 2009, XP Embedded, XP, Vista, 7, 8, 8.1, 10
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.4 to 10.10
Linux 3.5.x to 4.11.x LTS Versions Only

ENVIRONMENTAL
Humidity 5~85% RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -20°C to 85°C (-4°F to 185°F)

Certification
CE – FCC – ROHS

APPLICATION

Add more internal SATA ports to a computer system, to connect additional storage drives and/or optical drives
Upgrade an m.2-based system to SATA 6Gbps capability, to better utilize faster SATA drives
