EM30011

  • MINIPCIE 1-PORT RS232 & 1-PORT PARALLEL CARD
  • 1 high-speed RS232 serial port and 1 IEEE 1284 parallel port
  • Native single chip, single lane PCI Express
  • Selectable power output on pin 9 of the serial port
  • Automated in-band flow control using programmable Xon/Xoff
  • Compliant with PCI Express base specifications revision 1.1
HARDWARE
Mode Name EM30011
Bus Type Mini PCI-e
Card Type Embedded
Chipset ID ASIX Moschip-AX99100
Port Style Dongle (Included)
Interface Serial, Parallel IEEE 1284-compliant SPP/EPP/ECP
Port Numbers 2

PERFORMANCE
Data Bits 5, 6, 7, 8, 9
FIFO 128 Bytes
Flow Control Automated in-Band, Xon/Xoff
Max Baud Rate Parallel-1.5Mbps, Serial-115.2Kbps
Parity Even, Odd, Mark, Space, None
Serial Protocol RS-232

CONNECTOR(S)
Connector Type(s) 1-Mini PCI Express x1 (52 pin) Male
External Ports 1-DB-9 (9 pin, D-Sub) Male
1-DB-25 (25 pin, D-Sub) Female

System Requirements
Windows® XP Embedded, XP, Vista, 7, 8, 8.1, 10
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.4 to 10.10
Linux 3.5.x to 4.11.x LTS Versions Only

ENVIRONMENTAL
Humidity 5~85% RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -20°C to 85°C (-4°F to 185°F)

Certification
CE – FCC – ROHS

APPLICATION

Point-of-Sale (POS credit/debit card readers, receipt printers, bar code scanners, cash registers, scales)
Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers)
Connect specialized serial devices (printers, scanners, ISDN terminal adapters and memory card readers)
Environmental Control (lighting, temperature, clocks)
Entertainment (video lottery terminals, slot machines, gaming systems)
Healthcare (patient monitoring equipment, nurses’ stations, modems)
Security (UPS control, access key panels, video cameras, card readers, modems)
Hospitality/Restaurant (serial printers, bar code scanners, keyboard, mouse, receipt printer, credit/debit card reader)
Consumer (modems, PDAs, digital cameras, printers)ISDN Networking
