EMP0011
EMP0011
- MINIPCIE 1-PORT PARALLEL CARD
- 1 IEEE 1284 parallel port
- Native single chip, single lane PCI Express
- SPP/EPP/ECP Parallel port fully supports existing Centronics interface
- Supports x1,x2,x4,x8,x16(lane)PCI-Express connectors
- Compliant with PCI Express base specifications revision 1.1
| HARDWARE | |
| Mode Name | EMP0011 |
| Bus Type | Mini PCI-e |
| Card Type | Embedded |
| Chipset ID | ASIX Moschip-AX99100 |
| Port Style | Dongle (Included) |
| Interface | Parallel IEEE 1284-compliant SPP/EPP/ECP |
| Port Numbers | 1 |
PERFORMANCE |
|
| Max Baud Rate | Parallel-2.5Mbps |
| Parity | Even, Odd, Mark, Space, None |
CONNECTOR(S) |
|
| Connector Type(s) | 1-Mini PCI Express x1 (52 pin) Male |
| External Ports | 1-DB-25 (25 pin, D-Sub) Female |
System Requirements |
|
| Windows® XP Embedded, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 Mac OS® 10.4 to 10.10 Linux 3.5.x to 4.11.x LTS Versions Only |
|
ENVIRONMENTAL |
|
| Humidity | 5~85% RH |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
Certification |
|
| CE – FCC – ROHS | |
APPLICATION
| Connects any parallel peripheral including printers, scanners, CD-R/RWs, Zip® drives, and memory card readers. |
